Programmable Digital DC Power Watt Meter (Red LED w/ control)

Programmable Digital DC Power Watt Meter (Red LED w/ control)

SKU:
EPM-JLD404PWD-1R
$55.00
(No reviews yet)
Width:
3.00 (in)
Height:
4.00 (in)
Depth:
4.00 (in)
Current Stock:
Adding to cart… The item has been added
Description

This universal digital DC Power/Watt Meter has a single display with toggle(V,A), programmable Digital DC Power(Watt) meter. The meter is capable to measure a wide range of DC power by using a proper DC shunt(Not included). By default the meter can do DC 500v, 5A measurement without any addditional accessory.



Individual programmable control:

  • -Upper & lower limit setting
  • -Two alarm output J1, J2(Relay)
  • -DC shunt is programmable. Ex: 20A, 100A, 150A, 200A (all in 75mV)
  • -Toggle Display: P, Volt, Amp

Specifications

  • Display: Single display for P, V and I (amp)
  • Relay Output: Mechanical (3A max)
  • Power Handling: Default: 500V, 5A DC
  • Max: Unlimited (need DC 75mV shunt)
  • Accuracy: 0.5%
  • Operating voltage: DC 8V-30V
  • Mounting Hole Size: 91mm x 42.4
  • Dimension: 95.6mm x 47.5mmx81mm
