Industrial 3015 flatted bed fiber laser metal cutter

Industrial 3015 flatted bed fiber laser metal cutter

LightObject
SKU:
LSR_BS3015EC3
Availability:
Pre-order; please contact us for more details

GET A QUOTE BY EMAIL OR CALLING US.

(No reviews yet)
Width:
80.00 (in)
Height:
50.00 (in)
Depth:
160.00 (in)
Current Stock:
Description

EC3 Fiber Laser Metal Cutter

This is the basic but professional-grade fiber laser cutter features up to a 9000-watt fiber laser.  It is capable of cutting up to 800mm/s or frame speed at 1200mm/s with repeatability down to 0.03mm accuracy. This unit is the most popular laser machine in the market.

Fiber lasers offer increditable speed and precision as well as less job cleanup when compared to hybrid CO2 lasers or plasma cutters. This increased speed doesn’t come with drawbacks, the EC3 can cut through materials 50 times faster Hybrid CO2 Laser.

The EC3 also features an autofocus system for metal cutting applications, eliminating the need to manually focus the laser between jobs. In order to ensure high torque when driving the sizable gantry, the E3 utilizes dual-motor technology on the Y-axis. We have also utilized a Rack-pinion driven system in the EC3, eliminating the backlash and other inconsistencies that are commonly associated with belt-driven systems.

Setup is easier than ever thanks to the included PC with pre-loaded software, which also displays job progress in real-time and supports a wide variety of vector art formats. Due to the power output of this unit, water cooling is required. As such, a  2000W chiller is included with the purchase of this unit.

Example:

The EC3 with a 2000W laser source is capable of handling materials up to the following thicknesses:

16~17mm(5/8") Carbon Steel (O2)

6~7mm(1/4") Stainless Steel (N2)

4~5mm(3/16") Copper (N2)

4~5mm(3/16") Aluminum (N2)



Cutting performance data for 1000W - 4000W (for reference only)



Sample: 2000W

Thickness
(mm)		 Speed
(meter/min)		 Agent
(O2/N2)
Carbon Steel
1.0 45 Air
2.0 16 Air
3.0 3.4 O2
4.0 3.1 O2
5.0 2.7 O2
6.0 2.4 O2
8.0 1.5 O2
10 1.2 O2
12 1 O2
14 0.9 O2
16 0.8 O2
Stainless Steel
0.8 13.0~14.0 N2
1.0 10.0~12.0 N2
2.0 2.8~3.0 N2
3.0 1.2~1.5 N2
CuZn
1.0 10.0~12.0 N2
2.0 1.8~2.5 N2
Cu
1.0 5.0~6.0 O2
1.5 1.0~1.5 O2
Aluminum (Use with caution. Reflection may cause damage on the laser module)
1.0 18.0~20.0 O2
2.0 2.0~2.4 O2
3.0 1.0~1.5 O2

  Power:  2000W

  Operating voltage:
    - 1000~2000W: three-phase AC208V, 60Hz

  Type: Rack pinion with dual Y servo motors and branded linear guide

  Laser source: Max or Raycus

  Precision: 0.03mm , resolution: 0.03mm

  Auto focus: Dynamic auto focus laser head

  Water Protection: Yes

  Cutting agent: N2(nitrogen), O2(oxygen) or Air(customer provided)

  OS: Win11 ( 64 bit)

  Interface: USB

  USB memory drive support: Yes

  Real time simulation: Yes

  Cooling: Professional Water Chiller/ heater (included)

  Weight:3,000Kg/6000lb-7500lbs

The customer is responsible for unloading equipment such as a forklift.

  • Warranty: 2 year on machine
  • USA Support Team
    Free three days in-house training

* Price is different

Note: We only accept bank transfers and money orders. Full payment is required prior to delivery.












Additional Information
Work Area:
118" x 59" x 4.7"
Dimension:
160" x 80" x 50"
Z-table:
Cutting Head moving in Z direction
Power:
2000
Supported file format:
PLT, CDR, DXF, AI
